Automated Futsal Video Analysis for Performance Reporting
Computer Vision YOLOv11 DeepSORT Sports Analytics Action Recognition Multi-Object Tracking Deep Learning OCR Homography
Voir la démo

🎯 Executive Summary

During my final-year internship at SPORTSCORE, I developed an intelligent end-to-end AI pipeline for automated video analysis of futsal matches. The system transforms raw multi-camera footage into structured tactical insights by automatically detecting, tracking, and classifying player actions such as passes, shots, dribbles, interceptions, and goals.

Key Achievement: Reduced manual annotation workload by 80% while achieving 99.95% accuracy in frame classification and 90.1% precision in ball detection.

📋 Table of Contents

  1. Context & Problem Statement
  2. Company Background: SPORTSCORE
  3. Project Objectives
  4. Technical Architecture
  5. Core Pipeline Components
  6. Key Contributions
  7. Results & Performance
  8. Challenges & Solutions
  9. Impact & Business Value
  10. Future Perspectives
  11. Technical Stack

🔍 Context & Problem Statement

The Challenge

Traditional sports video analysis is:

  • ⏱️ Time-consuming: Manual annotation takes hours per match
  • 💰 Expensive: Requires dedicated video analysts
  • 🎯 Subjective: Human bias affects consistency
  • 🔄 Non-scalable: Cannot process multiple matches simultaneously

Futsal-Specific Complexities

Futsal presents unique challenges for automated analysis:

  • ⚡ Rapid gameplay with frequent transitions
  • 🏟️ Confined space causing constant occlusions
  • 🔄 High player density with overlapping trajectories
  • 🎥 Multi-camera setups requiring spatial alignment

The Solution

An AI-powered pipeline leveraging:

  • Computer Vision for object detection and tracking
  • Homography for 2D pitch projection
  • Spatio-temporal Rules for action recognition
  • Automated Classification to filter irrelevant frames

🏢 Company Background: SPORTSCORE

SPORTSCORE is an innovative French company specializing in real-time sports data exploitation using AI and computer vision. They develop software solutions that automatically extract:

  • 📊 Key events and statistics
  • 📈 Advanced tactical metrics
  • 🎨 Interactive visualizations

Target Clients:

  • Professional clubs and federations
  • Video analysts and coaches
  • Sports media and broadcasters

Mission: Transform sports through automation, precision, and speed of analysis.

🎯 Project Objectives

Primary Goals

  1. Intelligent Frame Filtering
    • Automatically exclude non-relevant sequences (replays, timeouts, transitions)
    • Reduce processing load and false positives
  2. Automated Action Detection
    • Detect and classify key actions: passes, shots, dribbles, interceptions
    • Generate structured event data (JSON format)
  3. Tactical Visualizations
    • Produce heatmaps, pass maps, and trajectory plots
    • Export performance reports for analysts
  4. Reduce Manual Workload
    • Minimize human annotation effort
    • Accelerate production of actionable insights

🏗️ Technical Architecture

System Overview

┌─────────────────────────────────────────────────────────────┐
│                    VIDEO INPUT (Multi-Camera)                │
└────────────────────┬────────────────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────────────────┐
│  MODULE 1: Frame Classification (YOLOv11m-cls)              │
│  ├─ Filter "Main" (useful) frames                           │
│  └─ Discard "Other" (replays, transitions)                  │
└────────────────────┬────────────────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────────────────┐
│  MODULE 2: Object Detection & Tracking                      │
│  ├─ YOLOv11x: Detect players & ball                         │
│  └─ DeepSORT: Multi-object tracking with Re-ID              │
└────────────────────┬────────────────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────────────────┐
│  MODULE 3: Spatial Projection (Homography)                  │
│  ├─ Map pixel coordinates → pitch coordinates               │
│  └─ Detect pitch lines & zones (penalty area, goal)         │
└────────────────────┬────────────────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────────────────┐
│  MODULE 4: Player Re-Identification                         │
│  ├─ HSV Clustering: Team color extraction                   │
│  ├─ OCR: Jersey number recognition                          │
│  └─ Trajectory-based identity confirmation                  │
└────────────────────┬────────────────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────────────────┐
│  MODULE 5: Pose Estimation (Keypoints)                      │
│  └─ Extract anatomical landmarks for gesture analysis       │
└────────────────────┬────────────────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────────────────┐
│  MODULE 6: Action Detection & Classification                │
│  ├─ Ball possession attribution                             │
│  ├─ Pass detection (7 types)                                │
│  ├─ Shot classification (on target, off target, blocked)    │
│  ├─ Dribble & interception detection                        │
│  └─ Goal confirmation & assist attribution                  │
└────────────────────┬────────────────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────────────────┐
│  OUTPUT: Structured Data (JSON) + Visualizations            │
│  ├─ Event timeline with timestamps                          │
│  ├─ Player trajectories & heatmaps                          │
│  ├─ Pass maps & tactical statistics                         │
│  └─ Automated performance reports                           │
└─────────────────────────────────────────────────────────────┘

⚙️ Core Pipeline Components

1. Frame Classification Module

Objective: Filter out non-relevant frames to reduce processing overhead.

Architecture: YOLOv11m-cls fine-tuned for binary classification

  • Class “Main”: Gameplay sequences (useful for analysis)
  • Class “Other”: Replays, timeouts, crowd shots, transitions

Training Data:

  • 67,801 annotated frames from multiple matches
  • Training set: 54,240 frames (25,655 Main + 28,585 Other)
  • Validation set: 13,561 frames (6,414 Main + 7,147 Other)

Performance:

  • Accuracy: 99.95%
  • Precision: 99.91% (only 6 false positives)
  • Recall: 100% (zero false negatives)
  • Impact: Reduced inference time from 19.98 min → 16.05 min (~20% speedup)

2. Object Detection & Multi-Object Tracking

Detection: YOLOv11x custom-trained on futsal datasets

  • Classes: Player, Ball, Referee, Goal
  • Ball Detection (Fine-tuned):
    • Precision: 90.1%
    • Recall: 83.4%
    • mAP@50: 83.4%

Tracking: DeepSORT with appearance-based association

  • Kalman Filter for motion prediction
  • Deep feature extraction (OSNet) for Re-ID
  • Dynamic buffer and adaptive matching threshold

Challenge: Ball often occluded or moving at high speed Solution: Created custom dataset with CVAT annotations from FIFA Futsal footage

3. Homography & Spatial Projection

Purpose: Convert pixel coordinates to real-world pitch coordinates

Method:

  1. Detect pitch keypoints (corners, circles, lines)
  2. Compute homography matrix
  3. Project player/ball positions onto 2D pitch model

Benefits:

  • Enables distance calculations between players
  • Validates actions based on pitch zones (penalty area, goal)
  • Generates tactical heatmaps and pass maps

4. Player Re-Identification (Re-ID)

Multi-Modal Approach:

  1. Team Detection: HSV color clustering on jerseys
  2. Jersey Number: OCR using PaddleOCR/Tesseract
  3. Trajectory Continuity: DeepSORT feature matching

Robustness: Maintains player identity despite:

  • Temporary occlusions
  • Camera angle changes
  • Posture variations

5. Pose Estimation & Keypoint Detection

Model: Pre-trained keypoint detector (OpenPose/MediaPipe)

Extracted Landmarks:

  • Head, shoulders, elbows, knees, ankles
  • Used to:
    • Detect shooting/passing gestures
    • Determine striking foot
    • Validate action types (e.g., header vs. foot pass)

6. Action Detection & Classification

Core Logic: Spatio-temporal rule-based system

Ball Possession Attribution

  • Methods tested:
    1. Distance to player center
    2. Distance to feet (via keypoints)
    3. Distance to bounding box center
    4. Distance to projected position
  • Solution: Temporal buffer + minimum distance heuristic

Pass Classification (7 Types)

Pass Type Criteria
Basic Pass Simple ball transmission between teammates
Progressive Pass Forward pass advancing >10m toward goal
Into-Penalty-Area Pass Pass ending inside opponent’s penalty area
Pressure Pass Pass made with opponent <2m away
Smart Pass Pass to unmarked teammate in attacking position
Key Pass Pass directly leading to a shot
Assist Pass directly leading to a goal

Shot Classification

  • Shot on Target: Ball directed toward goal without interception
  • Shot off Target: Ball misses goal frame
  • Blocked Shot: Shot blocked by defender before reaching goal

Other Actions

  • Dribble: Possession maintained while moving >1.5m
  • Interception: Opponent recovers pass attempt
  • Incomplete Pass: Pass not received after 2 seconds (~60 frames)
  • Goal: Ball enters goal mask zone with possession validation

🚀 Key Contributions

Contribution 1: Intelligent Frame Classification

Before:

  • All frames processed indiscriminately
  • High computational cost
  • Many false positives from replays

After:

  • 99.95% classification accuracy
  • 20% reduction in inference time
  • Cleaner event sequences

Training Process:

  1. Manual annotation using CVAT
  2. Fine-tuning YOLOv11m-cls (200 epochs)
  3. Integration as first pipeline stage

Contribution 2: Advanced Action Detection System

Developed from Scratch:

  • ActionDetection class with spatio-temporal logic
  • Ball possession tracking with temporal smoothing
  • 7-type pass classifier
  • Shot/dribble/interception detectors
  • Goal confirmation + automatic assist attribution

Logical Validation (Inspired by PoeClim):

  • Decision trees to verify actions post-detection
  • Example: Goal validated only if ball enters goal mask without possession change
  • Example: Assist attributed if goal preceded by Key/Smart/Progressive pass

Contribution 3: Performance Optimization

Ball Detection Enhancement:

  • Custom dataset: FIFA Futsal footage annotated in CVAT
  • Fine-tuned YOLOv11x (100 epochs, RTX 3090)
  • Results:
    • Precision: 90.1% (↑15% vs baseline)
    • Recall: 83.4%
    • Inference: 9.6ms/frame (~4.7 FPS)

Impact:

  • Reliable ball tracking in critical zones (goal area)
  • Accurate goal detection and assist attribution

Contribution 4: Structured Data Export

Output Formats:

  • JSON: Event timeline with timestamps, player IDs, coordinates
  • CSV: Tabular statistics for analysts
  • Visualizations: Heatmaps, pass maps, trajectory plots

Example JSON Structure:

{
  "event_id": 142,
  "type": "Progressive Pass",
  "timestamp": "12:34.56",
  "passer": {
    "id": 7,
    "team": "A",
    "position": [15.3, 22.1]
  },
  "receiver": {
    "id": 10,
    "team": "A",
    "position": [28.7, 18.9]
  },
  "outcome": "completed"
}

📊 Results & Performance

Quantitative Metrics

Metric Value
Frame Classification Accuracy 99.95%
Ball Detection Precision 90.1%
Ball Detection Recall 83.4%
Processing Speed 4.7 FPS (YOLOv11x)
Inference Time Reduction 20% (with frame filtering)
Manual Annotation Reduction ~80%

Qualitative Impact

✅ Automated Event Detection: No manual tagging needed for passes/shots/goals
✅ Reliable Re-ID: Players tracked consistently despite occlusions
✅ Tactical Insights: Heatmaps, pass networks, pressure zones generated automatically
✅ Scalable: Modular architecture ready for multi-match processing

🛠️ Challenges & Solutions

Challenge 1: Ball Detection in Critical Zones

Problem:

  • Ball often undetected near goal due to:
    • Small size + motion blur
    • Occlusion by goalkeeper/goalposts
    • High speed during shots

Solution:

  • Created custom dataset from FIFA Futsal footage
  • Fine-tuned YOLOv11x with 100 epochs
  • Added temporal smoothing to fill detection gaps

Result: 90.1% precision, enabling reliable goal confirmation

Challenge 2: Tracking Instability

Problem:

  • DeepSORT ID switches during player collisions
  • Ball tracking lost during occlusions

Solution:

  • Added temporal buffer for possession continuity
  • Integrated appearance features (OSNet) for Re-ID
  • Implemented Kalman filter predictions during gaps

Challenge 3: Action Ambiguity

Problem:

  • Differentiating pass types (e.g., Smart vs Key pass)
  • Validating incomplete passes vs interceptions

Solution:

  • Defined strict spatio-temporal rules:
    • Pressure Pass: opponent <2m from passer
    • Smart Pass: receiver unmarked + attacking zone
    • Key Pass: followed by shot within 3 seconds
  • Temporal validation windows (e.g., 60 frames for incomplete pass)

Challenge 4: Processing Time

Problem:

  • Full match (40 min) took ~60 minutes to process

Solution (Ongoing):

  • Implemented frame classification filter (20% speedup)
  • Prepared for multi-threading (batch processing)
  • Optimized data structures (dict → numpy arrays)

Target: Real-time processing (<1.5x match duration)

💼 Impact & Business Value

For SPORTSCORE

✅ Operational Efficiency: 80% reduction in manual annotation workload
✅ Scalability: Can now process multiple matches simultaneously
✅ Product Enhancement: Automated reports add value to client offerings
✅ Competitive Edge: Faster turnaround than manual analysis services

For Clients (Clubs, Analysts, Federations)

✅ Instant Insights: Match analysis available within hours (vs days)
✅ Objective Data: Eliminates human bias in event tagging
✅ Tactical Intelligence: Heatmaps, pass networks, pressure zones
✅ Player Development: Individual performance metrics for training

🔮 Future Perspectives

Short-Term Improvements

  1. Real-Time Processing
    • Optimize for <1.5x match duration
    • Implement GPU batch processing
    • Add multi-threading for parallel module execution
  2. Enhanced Ball Tracking
    • Integrate TrackNetV2 for ball trajectory prediction
    • Add segmentation-based detection for occluded ball
  3. Advanced Action Recognition
    • Train deep learning model (Transformer-based) for action spotting
    • Incorporate temporal context (xLSTM encoder)

Long-Term Vision

  1. Multi-Sport Extension
    • Adapt pipeline for basketball, handball, hockey
    • Transfer learning from futsal model
  2. Live Streaming Integration
    • Real-time event detection during broadcast
    • Automated highlight generation
  3. 3D Reconstruction
    • Multi-camera calibration for 3D player positioning
    • Depth estimation for offside detection
  4. Predictive Analytics
    • Expected Goals (xG) model
    • Pass success probability
    • Tactical pattern recognition (e.g., pressing schemes)

🛠️ Technical Stack

Deep Learning Frameworks

  • PyTorch 2.0 - Model training and inference
  • Ultralytics YOLOv11 - Object detection
  • TensorFlow/Keras - Supplementary models

Computer Vision Libraries

  • OpenCV - Video processing, homography
  • DeepSORT - Multi-object tracking
  • PaddleOCR - Jersey number recognition

Data Processing

  • NumPy - Numerical operations
  • Pandas - Data structuring
  • JSON - Event serialization

Annotation & Training

  • CVAT - Video annotation tool
  • Roboflow - Dataset management
  • Weights & Biases - Experiment tracking

Hardware

  • NVIDIA RTX 3090 (24GB VRAM) - Training
  • NVIDIA RTX 4060 (8GB VRAM) - Inference

📚 References & Related Work

This project builds upon state-of-the-art research in sports video analysis:

  1. PoeClim (Mohtaram et al., 2025): Spatio-temporal framework for action spotting
  2. Deep-EIoU (Huang et al., 2024): Advanced multi-object tracking
  3. YOLOv11 (Ultralytics, 2024): Latest YOLO architecture
  4. DeepSORT (Wojke et al., 2017): Deep association metric tracking

👨‍💻 About This Project

Duration: April 2025 - September 2025
Type: Final-Year Internship (Master’s in Artificial Intelligence)
Institution: Ibn Tofail University, Faculty of Sciences, Kenitra
Company: SPORTSCORE (Paris, France - Remote)
Supervisor: Mr. Noureddine Mohtaram (SPORTSCORE)
Academic Supervisor: Mr. Anass Nouri (FSK, Ibn Tofail University)

Jury Members:

  • Mr. Anass Nouri (FSK, Ibn Tofail University)
  • Mrs. Khadija Lekdioui (FSK, Ibn Tofail University)
  • Mrs. Khaoula Boukir (ENSC, Ibn Tofail University)

Defense Date: September 15, 2025

🎓 Skills Developed

Technical Skills

  • Advanced computer vision (detection, tracking, homography)
  • Deep learning model fine-tuning (YOLO, CNNs)
  • Multi-object tracking algorithms (DeepSORT, Kalman Filter)
  • Spatio-temporal reasoning and action recognition
  • Data pipeline design and optimization

Software Engineering

  • Modular code architecture
  • Performance profiling and optimization
  • Version control (Git) and collaboration
  • Documentation and technical writing

Domain Expertise

  • Sports analytics and tactical analysis
  • Video processing workflows
  • Real-time system design

📧 Contact & Links

Author: Hicham El Mehdi
Email: mehdihicham736@gmail.com
LinkedIn: linkedin.com/in/elmehdihicham
GitHub: github.com/MehdiHCH

Company Website: sportscore.tech (hypothetical)
Project Repository: github.com/MehdiHCH/futsal-analysis

This project represents a significant step toward fully automated sports video analysis, combining cutting-edge AI with domain expertise to deliver actionable insights for coaches, analysts, and federations.

← Retour aux projets
